Float glass cutting
Almacenamiento Y carga manual
SC-03SA Semiautomatic
Rack-type storage system with semi-automatic opening operated via a manual control that activates a hydraulic system. Its modular design allows adjustment of the support bases between 200 and 400 mm and accommodates glass sizes up to 3,700 × 2,600 mm.
The assisted opening facilitates handling, reduces operator effort and protects the material through smooth and safe movements.
- Maximum Glass Size: 3300 x 2600 mm - 96” x 108”
- Minimum Piece (Width): 1100 mm - 43”
- Support Height: 310 mm ±10 - 13,89”
- Aisle Width: 800 mm - 31,49
- Inclination: 4º
Technical specifications
| Models | A | Capacity | B |
|---|---|---|---|
| SC-03SA-200 | 200 mm - 7,87" | 3500 kg - 7716,18 lb | 315 mm - 12,40" |
| SC-03SA-250 | 200 mm - 7,87" | 4500 kg - 9920,80 lb | 365 mm - 14,37" |
| SC-03SA-300 | 300 mm -11,81" | 5500 kg - 12125,42 lb | 415 mm - 16,34" |
| SC-03SA-350 | 350 mm -13,78" | 6500 kg - 14330,05 lb | 465 mm - 18,31" |
| SC-03SA-400 | 400 mm -15,75" | 7500 kg - 16534,67 lb | 515 mm - 20,28" |
All our manual storage machines have...
Structural design
Customised load capacity
Coating of the bases
Heavy-duty guides.
Easy access to each sheet.
Versatility and efficiency
